ATS1 Architectural Surface - Curved Floating Center

Features

Backlit curved lens provides uniform illumination for visual comfort
Curved floating center detail creates a highly-aesthetic presence
Hinged door frame with optical assembly swings down to allow easy access from room side of fixture
Optional gasketed acrylic sani-shield lens helps protect against contaminants
HE option delivers superior efficacies up to 152 lm/W
Optional anti-microbial finish suppresses the spread of dangerous micro-organisms, mold, and bacterial growth
Diffuse or perforated lens options enhance the space
1x4, 2x2, and 2x4 sizes available
Six standard finish options and a wide selection of custom colors complement the architectural elements of any space
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
Build America, Buy America and Buy American Act compliant
Wireless in-fixture control solutions available
Made Right Here^® in the USA

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Housing	20-guage die-formated, welded C.R.S.
Door Frame	Hinged, flat, extruded aluminum door frame with optical assembly.
Shielding	Diffuse molded acrylic lens with center detail.
Finish	95% reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L70 >60,000 hours per IES TM-21. L80 > 102,000 hours with HE option. 50/60 Hz constant current driver.
Mounting	Surface or suspended
Listings	• cETLus conforms to UL STD 1598 and UL STD 8750. • Certified to CAN/CSA STD C22.2 No. 250.0. • Suitable for damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	20-guage die-formed, welded C.R.S.
Door Frame	Hinged, flat, extruded aluminum door frame with optical assembly.
Shielding	Diffuse molded acrylic lens with center detail.
Finish	95% reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L70 >50,000 hours per IES TM-21. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Surface or suspended
Listings	• cCSAus certified as luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
System Requirements	• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system • For additional PoE info, see details
