EXIT/EL Edge-lit Exit Sign

Red Letters/Clear Panel/Anodized Aluminum Housing
EXIT/EL: With a compact, low-profile design, EXIT/EL delivers ultra-bright, energy-efficient LED emergency lighting.
UL 924

Features

  • Compact, low-profile design
  • Choice of three finishes
  • UV-stabilized ultra-clear acrylic edge-lit panel provides consistent, uniform illumination
  • Ceiling, side, wall mount, or recessed
  • Available as full-time AC-powered unit or emergency unit with battery backup
  • EM unit provides 90 minutes of emergency operation
  • Ultra-bright, energy-efficient, long-life LEDs in red or green
  • Fully automatic solid-state two rate charger on EM unit recharges battery in 24 hours
  • Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
  • Directional indicators can be installed on-site
  • Custom message available
  • Self-diagnostic option performs monthly, biannual and annual tests to ensure reliable operation and meets electrical and life safety codes
  • Optional polycarbonate shield and wireguard provide added protection
  • Dual circuit option (AC-only) allows for connection to two different supplies at the same time

Tools

Product Builder

Configure fixtures and streamline the ordering process.

Find your local agent or distributor.

Specifications

Housing

Premium-grade extruded aluminum.

Electrical

Dual 120/277 voltage standard.

Mounting

Aluminum mounting canopy included for top, end or back mount.

Listings

 • UL 924 standard as an exit light suitable for dry or damp locations (0°C - +50°C).
• Meets NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
• Certified to CEC under Title 20 Regulations.

Downloads

Spec Sheets
Instructions
Literature

Accessories

Polycarbonate Shield

Wireguard
