MX2S 2″ Continuous – Surface

Features

Create elegant spaces with a seamless, continuous row of illumination
Specify in one-inch increments to create a perfect fit
Flat, glowing edge, drop and regressed lenses give designers a variety of looks
High-performance up to 115 lm/W
Linear extrusion contains snap-in light rails for ease of installation and maintenance
Versatile MX2 system includes recessed, surface, suspended and in-wall mounting
Factory installed row alignment system creates straight rows with ease
Fully illuminated corner configurations available
Diffuse acrylic lens provides uniform illumination for visual comfort
Design spaces quickly with the Linear Product Builder
Six standard finish options and a wide selection of custom colors complement the architectural elements of any space
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
Support human-centric design with adaptive, individualized lighting using tunable white light
Build America, Buy America and Buy American Act compliant
Wireless in-fixture control solutions available
Made Right Here^® in the USA

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Housing	Extruded aluminum with die-cast end plates.
Shielding	Extruded, flat, diffuse acrylic lens.
Finish	Textured matte white polyester TGIC powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. Reported L70: >54,000 hours. Reported L90: 52,000 hours. Estimated L70: 170,000 hours. 25°C maximum ambient operating temperature. 50/60 Hz constant current driver.
Mounting	Surface.
Listings	• cCSAus certified as luminaire suitable for dry or damp locations. • UL 924 available. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	Extruded aluminum with die-cast end plates.
Shielding	Extruded, flat, diffuse acrylic lens.
Finish	Textured matte white polyester TGIC powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED board. L70 > 60,000 hours per IES TM-21. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Surface.
Listings	• cCSAus certified as luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
System Requirements	• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system • For additional PoE info, see details

Housing	Extruded aluminum with die-cast end plates.
Shielding	Extruded, flat, diffuse acrylic lens.
Finish	Textured matte white polyester TGIC powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED board. L70 > 60,000 hours per IES TM-21. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses. 50/60 Hz constant current driver.
Mounting	Surface.
Listings	• cCSAus certified as luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
