PX WASH Perimeter Wall - Wash

Features

  • Subtly illuminate walls while providing low-glare ambient illumination
  • Sleek, linear design incorporates clean lines, slim styling, and a continuous row of light
  • Allows for 90° run connections in both inside and outside corner installs
  • Quick and easy installation with wall mounted bracket providing multiple pre- drilled screw locations and a quick hang feature for the fixture
  • Solutions for both grid and drywall ceilings
  • Adjustable extensions allow for a perfect fit to meet adjacent walls and create corners
  • Diffuse acrylic lens shields LEDs from view
  • Design spaces quickly with the Linear Product Builder
  • All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
  • Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
  • Support human-centric design with adaptive, individualized lighting using tunable white light
  • Buy American Act compliant
  • Wireless in-fixture control solutions available
  • Made Right Here® in the USA

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing

Formed sheet metal and aluminum.

Shielding

Extruded diffuse acrylic lens.

Finish

Textured matte white polyester TGIC powder coat bonded to phosphate-free, multistage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

Electrical

High-quality mid-power LED boards. L70 >60,000 hours per IES TM-21. 25°C maximum ambient operating temperature. 50/60 Hz constant current driver.

Mounting

Wall mount rail, predrilled with wall screw locations, with quick hang feature.

Listings

• cCSAus certified as luminaire suitable for dry or damp locations.
• DesignLights Consortium qualified product. Not all versions of this product may be DLC qualified, see the DLC Qualified Products List at www.designlights.org/QPL.
• Complies with the Buy American Act and other federal regulations. Request certification at hew.com/baa.

Warranty

5-year limited warranty, see details

Housing

Formed sheet metal and aluminum.

Shielding

Extruded diffuse acrylic lens.

Finish

Textured matte white polyester TGIC powder coat bonded to phosphate-free, multistage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

Electrical

High-quality mid-power LED board. L70 > 50,000 hours per IES TM-21. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.

Mounting

Wall mount rail, predrilled with wall screw locations, with quick hang feature. Maximum weight: 3.0 lbs/ft.

Listings

• cCSAus certified as luminaire suitable for dry or damp locations.
• Complies with the Buy American Act and other federal regulations. Request certification at hew.com/baa.

Warranty

5-year limited warranty, see details

System Requirements

• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system
• For additional PoE info, see details

Housing

Formed sheet metal and aluminum.

Shielding

Extruded diffuse acrylic lens.

Finish

Textured matte white polyester TGIC powder coat bonded to phosphate-free, multistage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

Electrical

High-quality mid-power LED board. L70 > 50,000 hours per IES TM-21. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses. 50/60 Hz constant current driver.

Mounting

Wall mount rail, predrilled with wall screw locations, with quick hang feature. Maximum weight: 3.0 lbs/ft.

Listings

• cCSAus certified as luminaire suitable for dry or damp locations.
• Complies with the Buy American Act and other federal regulations. Request certification at hew.com/baa.

Warranty

5-year limited warranty, see details
