AW Angled Narrow Wrap
Features
- Provides uniform downward light distribution and subtle side illumination
- Diffuse acrylic lens enhances uniformity and minimizes glare
- Wireway is accessible without the use of tools
- Six standard finish options and a wide selection of custom colors complement the architectural elements of any space
- Variety of mounting options for surface or suspended applications
- High-performance up to 143 lm/W
- All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
- DLC Compliant
- Build America, Buy America and Buy American Act compliant
- Wireless in-fixture control solutions available
- Made Right Here® in the USA
Tools
Estimate fixture quantities and light levels.
Configure fixtures and streamline the ordering process.
Use your zip code to find your local agent.
Find DLC Qualified or Energy Star certified products.
Calculate your ROI and lifetime energy use.
Specifications
|
Housing |
22-gauge die-formed C.R.S. |
|
Shielding |
Linear ribbed diffuse acrylic. |
|
Finish |
92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
|
Electrical |
High-quality mid-power LED boards. 50/60 Hz constant current driver. |
|
Mounting |
Surface or suspended. |
|
Listings |
• cCSAus certified as luminaire suitable for dry or damp locations. |
|
Warranty |
5-year limited warranty, see hew.com/warranty. |
