GS Slim High Bay

Features

  • Available on QuickShip
  • Ultra-low 2-9/16" fixture depth
  • Optimized for single-person installation
  • Up to 55ºC ambient rating
  • Multiple shielding and distribution options
  • High-performance up to 155 lm/W
  • Micro-prismatic lens reduces glare
  • Energy-saving alternative designed to replace traditional HID or fluorescent high bays
  • Non-EM fixtures are shipped in 2-packs to reduce job-site waste
  • DLC Compliant
  • Buy American Act compliant
  • Wireless in-fixture control solutions available
  • Made Right Here® in the USA

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Rebate Finder

Find DLC Qualified or Energy Star certified products.

Payback Calculator

Calculate your ROI and lifetime energy use.

Specifications

Housing

Die-formed aluminum housing.

Shielding

Clear or micro-prismatic acrylic lens.

Finish

92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

Electrical

45°C maximum ambient operating temperature standard. 55°C maximum ambient operating temperature when specified with HA option, lumen restrictions apply.

Mounting

Suspended. Surface mount kit available. Indoor applications only. Fixture weight is 6.5lbs for 2′ and 13lbs for 4′ unit, options may increase weight.

Listings

• cCSAus certified as luminaire suitable for dry or damp locations.
• DesignLights Consortium qualified product. Not all versions of this product may be DLC qualified, see the DLC Qualified Products List at www.designlights.org/QPL.
• Complies with the Buy American Act and other federal regulations. Request certification at hew.com/baa.

Warranty

5-year limited warranty, see details
