97 Enclosed & Gasketed Wide Distribution Industrial
Features
- Wide distribution optics are ideal for parking garage applications
- Fully gasketed fixture is built tough to resist contaminants
- Toggle latches ensure a tight seal and provide easy access to electrical components
- Closed-cell polyurethane gasket poured and formed in place to ensure tight seal–does not absorb water or support fungal growth
- Standard stainless steel latches protect the fixture from corrosion in harsh environments
- Tamper-resistant latches available
- Low ambient option for extreme cold environments such as walk-in freezers and refrigerated spaces
- NSF/ANSI 2, IP65, IP66 and IP67 certified, rated for NEMA 4X
- High-performance up to 148 lm/W
- Build America, Buy America and Buy American Act compliant
- Wireless in-fixture control solutions available
- Made Right Here® in the USA
Tools
Estimate fixture quantities and light levels.
Configure fixtures and streamline the ordering process.
Use your zip code to find your local agent.
Specifications
|
Enclosure |
Outer housing consists of 5VA (f1) fiberglass, rated for flame and weather resistance. |
|
Internal Housing |
.050″ aluminum. |
|
Latching |
Stainless steel latches. Injection-molded polycarbonate latches available (not recommended for use in harsh environments, such as a car wash). |
|
Reflector |
95% reflective highly specular aluminum. |
|
Shielding |
Frosted or clear, impact-resistant acrylic. |
|
Electrical |
High-quality mid-power LED board. L70 >60,000 hours. -20ºC to 40ºC maximum ambient operating temperature. -40ºC minimum operating temperature with LA40 option. 50/60 Hz constant current driver. |
|
Mounting |
Surface or suspended. Stainless steel ceiling mount brackets included. |
|
Listings |
• cETLus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for wet locations when specified with watertight hub, STOW or SOOW cord, or mini-male receptacle option. • NSF/ANSI Standard 2–Splash Zone certified, IP65, IP66, and IP67 certified, and rated for NEMA 4X. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american. |
|
Warranty |
5-year limited warranty, see details |
