FS FieldSELECT Strip
Features
- Available on QuickShip
- Easily change the color temperature and lumen output on-site with built in switches, providing ultimate flexibility
- End plate converts to row aligner for continuous row
- Small fixture profile allows inconspicuous placement in coves or confined spaces
- Diffuse acrylic lens enhances uniformity and minimizes glare
- Variety of mounting accessories for surface and suspended applications
- 4' and 8' lengths available
- High-performance up to 153 lm/W
- All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
- Build America, Buy America and Buy American Act compliant
- Made Right Here® in the USA
Tools
Estimate fixture quantities and light levels.
Configure fixtures and streamline the ordering process.
Use your zip code to find your local agent.
Specifications
Housing |
22-gauge die-formed C.R.S. |
Shielding |
Diffuse acrylic. |
Finish |
92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
Electrical |
High-quality mid-power LED boards. L70 >70,000 hours. 35°C maximum ambient operating temperature. 50/60 Hz constant current driver. |
Mounting |
Surface (ceiling or wall) or suspended (hanging hardware required). |
Listings |
• cETLus conforms to UL STD 1598. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/baa. |
Warranty |
5-year limited warranty, see details |
Downloads
- Quickship Brochure
- FS EM/10W KIT-QS
- FS-4-LS/8CS-QS-DIM-UNV
