FT FieldSELECT Troffer

Features

  • Easily change the color temperature and lumen output on-site with built in switches, providing ultimate flexibility
  • Low-profile depth for shallow plenum applications
  • Diffuse lens provides smooth illumination for visual comfort
  • High-performance up to 163 lm/W
  • Rated for direct contact with insulation
  • 1x4, 2x2, and 2x4 sizes available
  • Quick-wire access plate in back of fixture housing for easy attachment of incoming power supply
  • Buy American Act compliant
  • Made Right Here® in the USA

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing/Reflector

Precision die-formed 22-gauge C.R.S.

Shielding

Frosted acrylic.

Finish

Highly reflective non-glare matte white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

Electrical

High-quality mid-power LED boards. L70 >70,000 hours.

Mounting

NEMA Type “G” 15/16″ or 1″ grid standard. For NEMA Type “NFG” and “SG” 9/16″ grid installations, specify EQCLIPS option. Drywall flange kits available, shipped separately.

Listings

• cCSAus certified as luminaire suitable for dry locations.

• IC-rated for direct contact with insulation.

• City of Chicago Environmental Air approved when specified with CP option.

• Complies with the Buy American Act and other federal regulations. Request certification at hew.com/baa.

Warranty

5-year limited warranty, see details
