EXIT Exit Sign

Features

  • Available on QuickShip
  • Compact, low-profile design
  • Available as full-time AC-powered unit or emergency unit with battery backup
  • EM unit provides 90 minutes of emergency operation
  • Ultra-bright, energy-efficient, long-life LEDs in red or green
  • Fully automatic solid-state two-rate charger on EM units recharges battery in 24 hours
  • Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
  • Unique design allows double face conversion in the field
  • Removable directional indicators
  • Custom message available
  • Self-diagnostic option performs monthly, biannual, and annual tests to ensure reliable operation and meets electrical and life safety codes
  • Optional polycarbonate shield and wireguard provide added protection
  • Optional Salida faceplate
  • Dual circuit option (AC-only) allows for connection to two different supplies at the same time
  • Selectable red or green LEDs on-site with a built-in switch with FieldSELECT

Tools

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing

Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.

Electrical

Dual 120/277 voltage standard. 1.2V long life, maintenance-free, rechargeable NiCd battery.

Mounting

Mounting canopy for top or end mount. Universal knockout pattern on back plate for wall mount.

Listings

• UL 924 standard as an exit light suitable for dry or damp locations (0°C - +50°C).
• Meets NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
• Certified to CEC under Title 20 Regulations.

Warranty

5-year limited warranty.

Housing

Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.

Electrical

Dual 120/277 voltage standard. 1.2V long life, maintenance-free, rechargeable NiCd battery when specified with EM power option.

Mounting

Mounting canopy for top or end mount. Universal knockout pattern on back plate for wall mount.

Listings

• UL 924 standard as an exit light suitable for dry or damp locations (0°C - +50°C).
• Meets NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
• Certified to CEC under Title 20 Regulations.

Warranty

5-year limited warranty.

Accessories

Polycarbonate Shield

Wireguard

Housing Colors

Industry-Standard White

Black
