GL Low-Profile Industrial
Features
- Shallow fixture depth of less than 4" allows fixture placement near the ceiling for maximum space utilization and reduces damage incurred from material handling equipment
- Narrow distribution and uplight options provide tailored performance
- Quick-wire access plate for easy installation
- Aluminum housing for maximum heat dissipation
- Uplight modules available to illuminate dark ceilings
- HE option delivers superior efficacies up to 188 lm/W
- High ambient option for extreme environments
- Piano hinge and steel door frame options
- Optional wireguard provides added protection
- Variety of mounting options
- All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
- Build America, Buy America and Buy American Act compliant
- Wireless in-fixture control solutions available
- Made Right Here® in the USA
Tools
Estimate fixture quantities and light levels.
Configure fixtures and streamline the ordering process.
Find your local agent or distributor.
Specifications
|
Housing |
Die-formed aluminum housing. |
|
Finish |
92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
|
Electrical |
High-quality mid-power LED boards. L80 > 72,000 hours per IES TM-21. L80 > 102,000 hours with HE option. 40°C maximum ambient operating temperature standard. 60°C max when specified with HA option. 25°C max when specified with alternate drivers. 50/60 Hz constant current driver. |
|
Mounting |
Suspended. Indoor applications only. |
|
Listings |
• cCSAus certified as luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american. |
|
Warranty |
5-year limited warranty, see details |
|
Housing |
Die-formed 22-gauge C.R.S. housing. |
|
Reflector |
Precision-formed 95% reflective highly specular aluminum. |
|
Finish |
92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
|
Electrical |
Prewired for Type B, single or double end, non-shunted LED tubes, lamps by others. Refer to lamp manufacturer's specifications for additional requirements. |
|
Mounting |
Suspended. |
|
Listings |
• UL/CUL listed as LED suspended luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american. |
|
Warranty |
5-year limited fixture warranty, see details |
