HZL Hazardous Location Industrial

Features

  • Built tough for hazardous environments with Class 1-3, Division 2 certification, NSF, NEMA 4X, and IP67 ratings, and impact-resistant lens
  • Seamless closed-cell gasket, poured and formed in place, creates a vapor tight seal
  • Rigorously tested to withstand water penetration at 1500 PSI with 1.4 GPM flow rate, ensuring reliability in high-pressure washdown scenarios
  • Equipped with a liquid-tight power entry, reducing the risk of moisture ingress at critical electrical junctions
  • Precision illumination with standard wide or optional narrow distributions
  • Stainless steel latches provide long-lasting protection against corrosion
  • Precisely formed lens provides maximum efficiency/reduced glare
  • Tamper-resistant latches available for vandal-prone areas
  • High-performance up to 161 lm/W
  • Build America, Buy America and Buy American Act compliant
  • Made Right Here® in the USA

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Enclosure

Outer housing consists of 5VA (f1) fiberglass, rated for flame and weather resistance.

Internal Housing

.050″ aluminum.

Latching

Stainless steel latches, assembly, and gasket seals against water and dust ingress.

Reflector

95% reflective highly specular aluminum.

Reflective Surfaces

92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All internal parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.

Shielding

Frosted, impact-resistant acrylic.

Electrical

High-quality mid-power LED boards. L70 >50,000 hours. -20ºC to 40ºC maximum ambient operating temperature. 30°C max ambient when specified with EM battery. 6kV surge protection standard.

Temperature Code

T4 Standard | T5 Emergency

Power Entry

Fixture supplied with either watertight hub(s) or SOOW cord.

Mounting

Surface or suspended using four stainless steel mounting straps and two flexible ceiling mount brackets included.

Listings

• cETLus conforms to UL STD 1598. Certified to CAN/CSA STD C22.2 No. 250.0. Conforms to UL STD 844. Certified to CAN/CSA C22.2 STD No. 137-18. Suitable for wet locations with watertight hub, STOW or SOOW cord.
• Suitable for Class I, DIV. 2, Group A, B, C, D; Class II, DIV. 2, Group F, G; Class III DIV. 2
• NSF/ANSI Standard 2–Splash Zone certified, IP65, IP66, IP67 and NEMA 4X certified.
• Build America, Buy America (BABA) and Buy American Act (BAA) compliant.
Request certification at hew.com/buy-american

Warranty

5-year limited warranty, see details
