6CRDI COMPACT 6.5″ Direct/Indirect Cylinder – Round

6CRDI COMPACT: Williams 6.5 inch round direct and indirect LED cylinder with compact height features innovative TrimLock® reflector retention system to ensure trim remains secure.

Features

Engineered to deliver great performance in a sleek, space-saving design
Wide range of lumen options for general illumination
Smoothly accent walls and eliminate dark ceilings with direct and indirect lighting
Parallel the performance and style of the Williams downlight collection
Superior optical control with beams as narrow as 10° and field changeable optics as wide as 65°
Complement the architectural elements of any space with a multitude of housing, trim and cord finishes
Precision-engineered extruded aluminum housing and die-cast aluminum trim face for clean aesthetic
Variety of cord colors available in standard or braided for custom design
Open, flush, and regressed lens trim options
Reflectors create smooth, low-glare radiance
Innovative TrimLock® reflector retention system ensures trim remains secure
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Low UGR meets LEED and WELL requirements
Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
Support human-centric design with adaptive, individualized lighting using tunable white light
Mimic the comfortable, welcoming glow of incandescent with warm-dimming technology
Build America, Buy America and Buy American Act compliant
Wireless in-fixture control solutions available
Made Right Here^® in the USA

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi- stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic lens (acrylic downlight, tempered glass uplight).
Electrical	High-performance Class 2 C.O.B. LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>55,000 hours. Reported L90>55,000 hours. Estimated L70 = 200,000 hours.
Mounting	Cable or wall mount. Indoor applications only. Control, driver, and EM battery installed in remote mount box.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock^® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic lens (acrylic downlight, tempered glass uplight).
Electrical	High-performance Class 2 C.O.B. LED array. Modular quick-connect plug for easy field-connection of LED light assembly to node. Reported L70>50,000 hours. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Cable or wall mount. Indoor applications only.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
System Requirements	• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system • For additional PoE info, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic lens (acrylic downlight, tempered glass uplight).
Electrical	High-performance Class 2 LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>50,000 hours. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single- CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Cable or wall mount. Indoor applications only. Control, driver, and EM battery installed in remote mount box.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic lens (acrylic downlight, tempered glass uplight).
Electrical	High-performance Class 2 C.O.B. LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>55,000 hours. Reported L90>55,000 hours. Estimated L70 = 200,000 hours.
Mounting	Cable or wall mount. Indoor applications only. Control, driver, and EM battery installed in remote mount box.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
