6RCD 6″ Round Commercial Downlight
Features
-
Available on QuickShip
- Easily change the color temperature and lumen output on-site with built-in FieldSELECT™ switches, providing ultimate flexibility
- Simple and quick installation in new construction, IC-rated, or remodel applications
- 90 CRI provides high-accuracy color rendering
- Durable spring clips secure fixture
- Suitable for wet locations under covered ceiling
- Efficacies up to 105 lm/W
Tools
Estimate fixture quantities and light levels.
Configure fixtures and streamline the ordering process.
Use your zip code to find your local agent.
Find DLC Qualified or Energy Star certified products.
Calculate your ROI and lifetime energy use.
Specifications
Housing |
Aluminum housing. |
Trim |
Die-cast white stepped baffle with diffuse lens. |
Electrical |
Long-life LEDs provide estimated L70 >149,000 hours. 45ºC max ambient operating temperature. Complies with EN61000-4-5 surge protection (1kV). Harmonic distortion < 20%. Power factor > 0.90. |
Mounting |
Compatible with 6″- 6-3/4″ ceiling cutout. Heavy-duty mounting springs accommodate ceiling thicknesses up to 2-1/4″. New construction mounting pan accessory available. Access above ceiling required to change color and lumens after installation. Weight 1.4 lbs. |
Listings |
• cETLus listed as LED luminaire suitable for wet locations under covered ceiling. |
Warranty |
5-year limited warranty, see details. |
