6RCD 6″ Round Commercial Downlight

Features

  • Available on QuickShip
  • Easily change between five color temperatures and three lumen outputs on-site with built-in switches
  • Simple and quick installation in new construction, IC-rated, or remodel applications
  • 90 CRI provides high-accuracy color rendering
  • Durable spring clips secure fixture
  • Suitable for wet locations under covered ceiling
  • Efficacies up to 105 lm/W
  • Easily change the color temperature on-site with FieldSELECT

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Rebate Finder

Find DLC Qualified or Energy Star certified products.

Payback Calculator

Calculate your ROI and lifetime energy use.

Specifications

Housing

Aluminum housing.

Trim

Aluminum white stepped baffle with diffuse lens.

Electrical

Long-life LEDs provide estimated L70 >149,000 hours. 45ºC max ambient operating temperature for non IC-rated applications. Complies with EN61000-4-5 surge protection (1kV). Harmonic distortion < 20%. Power factor > 0.90.

Mounting

Compatible with 6″- 6-3/4″ ceiling cutout. Heavy-duty mounting springs accommodate ceiling thicknesses up to 2-1/4″. New construction mounting pan accessory available. Access above ceiling required to change color and lumens after installation. Weight 1.4 lbs.

Listings

• cETLus listed as LED luminaire suitable for wet locations under covered ceiling.
• Conforms to UL STD.1598. Certified to CSA STD.C22.2 No.250.0.
• Complies with FCC Part 15, Class B.
• IC-rated for direct contact with insulation.
• ENERGY STAR® certified in select configurations, see www.energystar.gov

Warranty

5-year limited warranty, see details.
