6CR 6.5″ Cylinder – Round

6CR: The modern design of the 6 inch round LED cylinder features precision illumination with 10° narrow to 65° wide optics.

Features

Wide range of lumen options for general illumination
Parallel the performance and style of the Williams downlight collection
Superior optical control with beams as narrow as 10° and field changeable optics as wide as 65°
Complement the architectural elements of any space with a multitude of housing, trim and cord finishes
Comprehensive list of mounting options – pendant, cable, power cord, wall and ceiling
Ensure a simple and secure installation with TwistLock™ surface mount technology
Precision-engineered extruded aluminum housing and die-cast aluminum trim face for clean aesthetic
Variety of cord colors available in standard or braided for custom design
Open, flush, and regressed lens trim options
Reflectors create smooth, low-glare radiance
Innovative TrimLock® reflector retention system ensures trim remains secure
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Low UGR meets LEED and WELL requirements
Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
Support human-centric design with adaptive, individualized lighting using tunable white light
Mimic the comfortable, welcoming glow of incandescent with warm-dimming technology
Create rich, vibrant designs with lasting visual impact using the full visible light spectrum
Build America, Buy America and Buy American Act compliant
Wireless in-fixture control solutions available
Made Right Here^® in the USA

Tools

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic, acrylic lens.
Electrical	High-performance Class 2 C.O.B. LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>55,000 hours. Reported L90>55,000 hours. Estimated L70 = 200,000 hours.
Mounting	Surface, cable, pendant, power cord, or wall mount. Indoor applications only. Max weight 9-1/2 lbs.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic, acrylic lens.
Electrical	High-performance Class 2 LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>50,000 hours. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Surface, cable, pendant, or wall mount. Indoor applications only. Max weight 9-1/2 lbs.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
System Requirements	• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system • For additional PoE info, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic, acrylic lens.
Electrical	High-performance Class 2 LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>50,000 hours. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Surface, cable, pendant, power cord, or wall mount. Indoor applications only. Max weight 9-1/2 lbs.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with micro-prismatic, acrylic lens.
Electrical	High-performance Class 2 C.O.B. LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>55,000 hours. Reported L90>55,000 hours. Estimated L70 = 200,000 hours.
Mounting	Surface, cable, pendant, power cord, or wall mount. Indoor applications only. Max weight 9-1/2 lbs.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	Extruded aluminum with die-cast aluminum accent ring.
Finish	Polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Trimlock	Innovative TrimLock® reflector retention system ensures trim remains secure.
Open Reflector	Low-iridescent anodized aluminum with top diffuser. Clear semi-specular finish standard.
Lensed Trim	Die-cast aluminum frame with microprismatic, acrylic lens.
Electrical	High-performance Class 2 CSP RGBW LED array. Modular quick-connect plug for easy field-connection of LED light assembly to driver. Reported L70>60,000 hours (all colors). Reported L90: Red: >23,000 hours, Green: >44,000 hours, Blue: >60,000 hours, White: >48,000 hours
Control	DMX enabled; controllers provided by others.
Mounting	Surface, cable, pendant, power cord, or wall mount. Indoor applications only. Max weight 9-1/2 lbs. Control and EM battery installed in remote mount box.
Listings	• cCSAus conforms to UL STD 1598 and UL STD 8750. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for dry and damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american
Warranty	5-year limited warranty, see details
