75R Round Lens Narrow Strip

Features

Available on QuickShip
Diffuse acrylic lens enhances uniformity and minimizes glare
Round lens provides a clean look for architectural environments
Variety of surface and suspended mounting accessories
Small profile allows inconspicuous placement in confined spaces
Row applications produce continuous light with minimal interruption between fixtures
HE option delivers superior efficacies up to 182 lm/W
Optional wireguard provides added protection
Six standard finish options and a wide selection of custom colors complement the architectural elements of any space
2', 3', 4', and 8' lengths available
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Quick-connect wiring options for continuous row mounting
Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
Support human-centric design with adaptive, individualized lighting using tunable white light
Create rich, vibrant designs with lasting visual impact using the full visible light spectrum
DLC Compliant
Build America, Buy America and Buy American Act compliant
Wireless in-fixture control solutions available
Made Right Here^® in the USA

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Rebate Finder

Find DLC Qualified or Energy Star certified products.

Payback Calculator

Calculate your ROI and lifetime energy use.

Housing	22-gauge die-formed C.R.S.
Shielding	Diffuse acrylic lens. Frosted polycabonate optional.
Finish	92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED board. L70 > 72,000 hours per IES TM-21. L80 > 102,000 hours with HE option. 25°C maximum ambient operating temperature. 40°C maximum ambient operating temperature with HA Option, lumen restrictions apply. 50/60 Hz constant current driver.
Mounting	Surface (ceiling or wall) or suspended (hanging hardware required).
Listings	• cETLus conforms to UL STD 1598. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for damp locations. • UL 924 available. • DesignLights Consortium qualified product. Not all versions of this product may be DLC qualified, see the DLC Qualified Products List at www.designlights.org/QPL. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	22-gauge die-formed C.R.S.
Shielding	Diffuse acrylic lens.
Finish	92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L70 >50,000 hours per IES TM-21. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses.
Mounting	Surface (ceiling or wall) or suspended (hanging hardware required).
Listings	• cETLus conforms to UL STD 1598. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
System Requirements	• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system • For additional PoE info, see details

Housing	22-gauge die-formed C.R.S.
Shielding	Diffuse acrylic lens.
Finish	92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L70 >50,000 hours per IES TM-21. Tunable White products use LEDs of multiple shade of white from single- CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses. 50/60 Hz constant current driver.
Mounting	NEMA Type “G”. Surface mount and drywall kit accessories available, ordered separately.
Mounting	Surface (ceiling or wall) or suspended (hanging hardware required).
Listings	• cETLus conforms to UL STD 1598. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	22-gauge die-formed C.R.S.
Shielding	Diffuse acrylic lens. LED pixelation may occur with some color mixes. Use in applications where the lens is not visible at close distances for best results.
Finish	92% minimum average reflective white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L70 >60,000 hours per IES TM-21. 25ºC maximum ambient operating temperature. 50/60 Hz constant current driver.
Control	DMX enabled; controllers provided by others.
Mounting	Surface (ceiling or wall) or suspended (hanging hardware required).
Listings	• cETLus conforms to UL STD 1598. Certified to CAN/CSA STD C22.2 No. 250.0. Suitable for damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
