RNDP Round Architectural Pendant

Features

Provides soft, uniform ambient illumination
Lift-and-twist lens assembly allows for easy maintenance
2', 3', and 4' diameters available
Round, suspended architectural fixture adds visual interest to a variety of applications
Combine multiple mounting types to create a unique and modern space
Sleek aircraft cable or pendant mount
High-performance up to 143 lm/W
Six standard finish options and a wide selection of custom colors complement the architectural elements of any space
All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Deliver scalable, data-driven smart buildings with PoE-enabled fixtures and controls
Build America, Buy America and Buy American Act compliant
Wireless in-fixture control solutions available
Made Right Here^® in the USA

Quantity Estimator

Estimate fixture quantities and light levels.

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Housing	.080″ spun aluminum outer housing with C.R.S. back plate.
Shielding	Frosted acrylic lens, .125″ thick.
Finish	Textured matte white polyester TGIC powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L85 at 50,000 hours. 25ºC maximum ambient operating temperature. 50/60 Hz constant current driver.
Mounting	Suspended. Adjustable steel aircraft cable mounts to 1/4-20 stud provided by others; or use 3/8″ IPS stem and canopy kit.
Listings	• cCSAus certified as luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details

Housing	.080″ spun aluminum outer housing with C.R.S. back plate.
Shielding	Frosted acrylic lens, .125″ thick.
Finish	Textured matte white polyester TGIC powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion.
Electrical	High-quality mid-power LED boards. L85 at 50,000 hours. Low-voltage DC fixture, to be fed by Class 2 power supply.
Mounting	Suspended. Adjustable steel aircraft cable mounts to 1/4-20 stud provided by others; or use 3/8″ IPS stem and canopy kit.
Listings	• cCSAus certified as luminaire suitable for dry or damp locations. • Build America, Buy America (BABA) and Buy American Act (BAA) compliant. Request certification at hew.com/buy-american.
Warranty	5-year limited warranty, see details
System Requirements	• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system • For additional PoE info, see details
