LT Troffer
Features
-
Available on QuickShip
- Low-profile depth for shallow plenum applications
- Diffuse lens provides smooth illumination for visual comfort
- Surface mount kit preserves continuity
- High-performance up to 140 lm/W
- 1x4, 2x2, and 2x4 sizes available
- Quick-wire access plate in back of fixture housing for easy attachment of incoming power supply
- Easily change the color temperature on-site with FieldSELECT™
- Deliver scalable, data-driven smart buildings with Platformatics PoE-enabled fixtures and controls
- Support human-centric design with adaptive, individualized lighting using tunable white light
- DLC Compliant
- Buy American Act compliant
- Available with Avi-on wireless fixture controls
- Made Right Here® in the USA
Tools
Estimate fixture quantities and light levels.
Configure fixtures and streamline the ordering process.
Use your zip code to find your local agent.
Find DLC Qualified or Energy Star certified products.
Calculate your ROI and lifetime energy use.
Specifications
Housing/Reflector |
Precision die-formed 22-gauge C.R.S. |
Shielding |
Frosted acrylic. |
Finish |
Highly reflective non-glare matte white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
Electrical |
High-quality mid-power LED boards. L80 >60,000 hours. |
Mounting |
Designed for NEMA Type “G” 1″ grid ceiling standard. For NEMA Type “NFG” and “SG” 9/16″ grid installations, specify EQCLIPS option. Surface mount and drywall kit accessories available, shipped separately. |
Listings |
• cCSAus certified as luminaire suitable for dry or damp locations. |
Warranty |
5-year limited warranty, see details |
Housing/Reflector |
Precision die-formed 22-gauge C.R.S. |
Shielding |
Frosted acrylic. |
Finish |
Highly reflective non-glare matte white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
Electrical |
High-quality mid-power LED boards. L70 >50,000 hours per IES TM-21. Low-voltage DC fixture, to be fed by Class 2 power supply. Tunable White products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses. |
Mounting |
Designed for NEMA Type “G” 1″ grid ceiling standard. For NEMA Type “NFG” and “SG” 9/16″ grid installations, specify EQCLIPS option. Surface mount and drywall kit accessories available, shipped separately. |
Listings |
• cCSAus certified as luminaire suitable for dry or damp locations. |
Warranty |
5-year limited warranty, see details |
System Requirements |
• PoE-ready luminaires are connected to building power systems through network integration and require other components for complete PoE lighting system |
Housing/Reflector |
Precision die-formed 22-gauge C.R.S. |
Shielding |
Frosted acrylic. |
Finish |
Highly reflective non-glare matte white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
Electrical |
High-quality mid-power LED boards. L70 >50,000 hours per IES TM-21. Tunable White products use LEDs of multiple shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdam ellipses. |
Mounting |
Designed for NEMA Type “G” 1″ grid ceiling standard. For NEMA Type “NFG” and “SG” 9/16″ grid installations, specify EQCLIPS option. Surface mount and drywall kit accessories available, shipped separately. |
Listings |
• cCSAus certified as luminaire suitable for dry or damp locations. |
Warranty |
5-year limited warranty, see details |
Housing/Reflector |
Precision die-formed 22-gauge C.R.S. |
Shielding |
Frosted acrylic. |
Finish |
Highly reflective non-glare matte white polyester powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion. |
Electrical |
High-quality mid-power LED boards with switchable CCT – 3000K, 3500K, and 4000K. L70 >50,000 hours. FieldSELECT products use LEDs of multiple CCTs and may produce a perceptibly different shade of white from single-CCT products at the same CCT. All CCTs are within 3 MacAdams ellipses. |
Mounting |
Designed for NEMA Type “G” 1″ grid ceiling standard. For NEMA Type “NFG” and “SG” 9/16″ grid installations, specify EQCLIPS option. Drywall kit accessories available for flange applications, shipped separately. |
Listings |
• cCSAus certified as luminaire suitable for dry locations. |
Warranty |
5-year limited warranty, see details |
